Render and Action methods in Spring MVC portlet in Liferay

Spring MVC Portlet in Liferay provides facility to define multiple render and action methods. Liferay MVC portlet however allow one render method and multiple action methods.

In this article, we will see how to write multiple render and action methods in Spring MVC portlet created in Liferay. This article is an addendum of my previous blog Spring MVC Portlet in Liferay So Please refer it to understand how to create Spring MVC portlet.

Define multiple render and action methods


In last blog
(Spring MVC Portlet in Liferay) we have created default render method. We will continue the same example in that blog and will see the following things.

  • Create Render method with “action” as key
  • call Action method with “action” as key with Default Render method
  • call Action method with “action” as key with Specific Render method

Create Render method with “action” as key

We have seen how to create default render method which will be called on page refresh. In some situation, the logic in render method become complex and needs to be divided in multiple small methods.

One of the solution is that, we can define independent chunk of code in separate method and call it in default render() method. The issue in this approach is we will end up in defining multiple if-else condition and have to set different flag value.

Spring MVC Portlet address this issue effectively by allowing us to define multiple render and action methods. This help us to divide render logic in multiple methods. Each render method can be called with render URL by passing different action KEY.

Let us do it practically.

Add following code in MyFirstSpringMVCTestController  class

Explanation:-

  • This method having @RenderMapping annotation with params attribute.
  • The value of params  is action=renderOne. It means this render method will be called when we create RenderURL from JSP and pass action parameter with value renderOne
  • In another word, the key of this render method(value of action) should be match with the value of action request parameter that we pass in renderURL
  • This method return string “render1″. It means it will render “render1.jsp“. This is similar concept that we have seen for default Render method in previous blog (the returning string represent the jsp name).
  • Method name can be anything you want.
Create Jsp file called render1.jsp at the same path (WEB-INF/jsp)where we have created defaultRender.jsp and add following code.

 Explanation:-
  • First we have added portlet taglib reference which used to create render URL.
  • Next, I have created renderURL with the help of <portlet:renderURL> tag. We have given var name so that it can be referred anywhere in the page with JSTL. We also passed portlet parameter called action and its value is “renderOne”
  • Then I have added header – This is Default Render Jsp.
  • If you notice, I kept same value of action parameter in render URL with the value of action key for renderOneMethod method in annotation. It means this renderURL will call the render method (in spring controller) having action key matching with action parameter value in render URL.
Now its time to see our work. Build and deploy the portlet. We already place the portlet on liferay page. So just refresh it to see the changes. You can notice that the defaultRender jsp get render and generate output as per below screenshot.
Multiple render and action methods in Spring MVC portlet - default-render-method

Now click on link Call RenderOne method and you will notice that the rende1.jsp get displayed as per below screenshot.
Multiple render and action methods in Spring MVC portlet - render1-method
If you want, you can put logger at each method to see the flow of execution.

Call Action method with “action” as key with Default Render method

We can create the Action method with similar way we have created the above Render method. Add the code in defaultRender.jsp so that it will looks like below snippet.



Explanation:-

  • We have now created actionURL with the help of portlet:actionURL tag. I set var = actionOneMethodURL. This means it can be refer by ${actionOneMethodURL} anywhere in jsp.
  • We also have passed action parameter with value “actionOne”
  • We will create the action method in controller class with action key and set its value as “actionOne” so that it can be call when this actionURL is clicked from JSP.
  • At the end we had created html form with one input text and submit button. The action of the form will be actionURL created by <portlet:action> tag.
  • Here the concept will be same as renderURL. When we hit the submit button, the respective action method will be called who’s action key value is matched with the action parameter value in  <portlet:action> tag.
Next, we will create action method as per below snippet in controller class.

Explanation:-

  • We have created action method with annoation @ActionMapping and its param attribute is “action=actionOne”. It means this action method have key action and its value is actionOne
  • So this method will be called by actionURL who’s action parameter value is “actionOne”.
  • Method name can be anything you want.
  • In this method, I am accessing request parameter through Liferay utility class(ParamUtil).
  • At the last, I am printing the request parameter through logger. You can create logger in Liferay by creating class level static variable with the help of Liferay utility class LogFactoryUtil as shown in below snippet.

  • We have to pass class reference in which we are defining logger in getLog method
  • You can notice that, we not returning anything. I mean the return type of this method is void.
  • So you may wonder, after this method get executed what is the output. And the answer is it will execute default Render method.
Now its time to see this in action. Deploy the portlet and you will see the portlet get rendered as per below screenshot.
Multiple render and action methods in Spring MVC portlet - action-method-1
Give any value in text box, say Nilang and click on Submit button. You will notice that the same jsp (defaultRender.jsp) will be displayed. You can check the logs and confirm that control goes to action method and execute the logs and then execute the default render method. Below is the snapshot of logs.
Multiple render and action methods in Spring MVC portlet - log

You can put log in default render method to understand it more clear.

Call Action method with “action” as key with Specific Render method

As per portlet specification, render method will be called soon after action method completes its execution. In case of Spring MVC Portlet, default render method will be called after completion of action method.This is default behavior.
Spring MVC portlet framework provides a way to execute specific render method instead of default render after completion of action method.

Let’s see how to achieve this. Create one render method as per below snippet.

Explanation:-

  • we created new render method with its key action set to renderAfterAction. Also we are returning “renderAfterAction“. Means it will search for renderAfterAction.jsp file under /WEB-INF/jsp folder.
  • After completion of action method, we would like to call this newly define render method instead of default render method.
Create new jsp file renderAfterAction under /WEB-INF/jsp folder and just enter one line content in it like “<h1>This is Render After Action JSP </h1>

Modify action method as per below code snippet.


Explanation:-

  • The only change we have done is added last line code response.setRenderParameter(“action”, “renderAfterAction”);
  • This will tell controller that after executing the action method, set render parameter action to “renderAfterAction“.
  • It means, the action method wants to execute specific render method with value of action key set to  renderAfterAction
  • So after executing this action method it will execute testRenderMethod (who’s value of action key is renderAfterAction)
Note:- setRenderParameter method is available only for object of type ActionResponse.

Deploy the folder and it will show defaultRender jsp. Give the name as “Nilang” and click on Submit button. You will see the render method renderAfterAction get execute as per below screen shot.
Multiple render and action methods in Spring MVC portlet - render-after-action
You also can notice the log to understand the flow as per below screenshot.
log2
You can notice that after the action method get executed, control goes to testRenderMethod method. Its done. you can try some more Actions and Render method combination to get more dipper knowledge.

Summing Up

  • Spring MVC Portlet supports multiple render and action methods.
  • Multiple render and action methods are useful to define multiple render and action logic.
  • Liferay MVC Portlet supports one render and multiple action methods while spring MVC portlet allow to define multiple render and action methods.

I would recommend looking at index page ‘A Complete Liferay Guide‘ to browse all topics about liferay.
