Render and Action methods in Spring MVC portlet in Liferay

— June 26, 202196 comments
Spring MVC Portlet in Liferay provides a facility to define multiple render and action methods. Liferay MVC portlet however allows one render method and multiple action methods.

In this article, we will see how to write multiple render and action methods in the Spring MVC portlet created in Liferay. This article is an addendum to my previous blog Spring MVC Portlet in Liferay So Please refer to it to understand how to create a Spring MVC portlet.

Define multiple render and action methods


In the last blog (Spring MVC Portlet in Liferay) we have created the default render method. We will continue the same example in that blog and will see the following things.

  • Create Render method with “action” as key
  • call Action method with “action” as key with Default Render method
  • call Action method with “action” as key with Specific Render method

Create Render method with “action” as key

We have seen how to create a default render method which will be called on page refresh. In some situation, the logic in render method become complex and needs to be divided in multiple small methods.

One of the solutions is that we can define an independent chunk of code in a separate method and call it in the default render() method. The issue in this approach is we will end up defining multiple if-else conditions and have to set different flag values.

Spring MVC Portlet address this issue effectively by allowing us to define multiple render and action methods. This helps us to divide render logic into multiple methods. Each render method can be called with render URL by passing different action KEY.

Let us do it practically.

Add following code in MyFirstSpringMVCTestController  class
@RenderMapping(params = "action=renderOne")
public String renderOneMethod(RenderRequest request, RenderResponse response, Model model){
  return "render1";
 }

Explanation:-

  • This method having @RenderMapping annotation with params attribute.
  • The value of params  is action=renderOne. It means this render method will be called when we create RenderURL from JSP and pass action parameter with value renderOne
  • In another word, the key of this render method(value of action) should be matched with the value of action request parameter that we pass in renderURL
  • This method return string “render1″. It means it will render “render1.jsp“. This is a similar concept that we have seen for the default Render method in a previous blog (the returning string represents the JSP name).
  • Method name can be anything you want.
Create JSP file called render1.jsp at the same path (WEB-INF/jsp)where we have created defaultRender.jsp and add the following code.
<%@ taglib uri="http://java.sun.com/portlet_2_0" prefix="portlet" %>
<portlet:renderURL var="renderOneMethodURL">
	<portlet:param name="action" value="renderOne"/>
</portlet:renderURL>

<h1>This is Default Render Jsp</h1>
<a href="${renderOneMethodURL}">Call RenderOne method</a>
 Explanation:-
  • First, we have added portlet taglib reference which used to create render URL.
  • Next, I have created renderURL with the help of <portlet:renderURL> tag. We have given var name so that it can be referred anywhere on the page with JSTL. We also passed a portlet parameter called action and its value is “renderOne”
  • Then I have added a header – This is Default Render Jsp.
  • If you notice, I kept the same value of action parameter in render URL with the value of action key for renderOneMethod method in the annotation. It means this renderURL will call the render method (in spring controller) having action key matching with action parameter value in render URL.
Now it’s time to see our work. Build and deploy the portlet. We already place the portlet on the Liferay page. So just refresh it to see the changes. You can notice that the defaultRender jsp gets render and generate output as per the below screenshot.
Multiple render and action methods in Spring MVC portlet - default-render-method

Now click on link Call RenderOne method and you will notice that the rende1.jsp get displayed as per the below screenshot.
Multiple render and action methods in Spring MVC portlet - render1-method
If you want, you can put a logger at each method to see the flow of execution.

Call Action method with “action” as key with Default Render method

We can create the Action method in a similar way we have created the above Render method. Add the code in defaultRender.jsp so that it will look like the below snippet.

<%@ taglib uri="http://java.sun.com/portlet_2_0" prefix="portlet" %>
<portlet:renderURL var="renderOneMethodURL">
	<portlet:param name="action" value="renderOne"/>
</portlet:renderURL>

<portlet:actionURL var="actionOneMethodURL">
	<portlet:param name="action" value="actionOne"/>
</portlet:actionURL>

<h1>This is Default Render Jsp</h1>
<a href="${renderOneMethodURL}">Call RenderOne method</a>
<form action="${actionOneMethodURL}" method="post">User Name: <input name="userName" type="text" />
<input type="submit" /></form><span style="font-family: inherit;">

Explanation:-

  • We have now created actionURL with the help of portlet:actionURL tag. I set var = actionOneMethodURL. This means it can be refer by ${actionOneMethodURL} anywhere in jsp.
  • We also have passed action parameter with value “actionOne”
  • We will create the action method in the controller class with action key and set its value as “actionOne” so that it can be called when this actionURL is clicked from JSP.
  • In the end, we had created an HTML form with one input text and submit button. The action of the form will be actionURL created by <portlet:action> tag.
  • Here the concept will be the same as renderURL. When we hit the submit button, the respective action method will be called whose action key value is matched with the action parameter value in  <portlet:action> tag.
Next, we will create an action method as per the below snippet in the controller class.
@ActionMapping(params = "action=actionOne")
 public void actionOneMethod(ActionRequest request, ActionResponse response) {
  String userName=ParamUtil.get(request, "userName", "");
  log.info("userName is==>"+userName);
 }

Explanation:-

  • We have created an action method with annotation @ActionMapping and its param attribute is “action=actionOne”. It means this action method has key action and its value is actionOne
  • So this method will be called by actionURL who’s action parameter value is “actionOne”.
  • Method name can be anything you want.
  • In this method, I am accessing request parameters through the Liferay utility class(ParamUtil).
  • At the last, I am printing the request parameter through a logger. You can create a logger in Liferay by creating a class level static variable with the help of the Liferay utility class LogFactoryUtil as shown below snippet.
private static Log log = LogFactoryUtil.getLog(MyFirstSpringMVCTestController.class);
  • We have to pass class reference in which we are defining logger in getLog method
  • You can notice that we not returning anything. I mean the return type of this method is void.
  • So you may wonder after this method gets executed what is the output. And the answer is it will execute the default Render method.
Now it’s time to see this in action. Deploy the portlet and you will see the portlet get rendered as per the below screenshot.
Multiple render and action methods in Spring MVC portlet - action-method-1
Give any value in the text box, say Nilang, and click on Submit button. You will notice that the same JSP (defaultRender.jsp) will be displayed. You can check the logs and confirm that control goes to the action method and execute the logs and then execute the default render method. Below is the snapshot of logs.
Multiple render and action methods in Spring MVC portlet - log

You can put a log in the default render method to understand it more clear.

Call Action method with “action” as key with Specific Render method

As per portlet specification, the render method will be called soon after the action method completes its execution. In the case of Spring MVC Portlet, the default render method will be called after completion of the action method. This is the default behavior.
Spring MVC portlet framework provides a way to execute a specific render method instead of default render after completion of the action method.

Let’s see how to achieve this. Create one render method as per the below snippet.
@RenderMapping(params = "action=renderAfterAction")
 public String testRenderMethod(RenderRequest request, RenderResponse response){
  log.info("In renderAfterAction method");
  return "renderAfterAction";
 }

Explanation:-

  • we created a new render method with its key action set to renderAfterAction. Also we are returning “renderAfterAction“. Means it will search for renderAfterAction.jsp file under /WEB-INF/jsp folder.
  • After completion of the action method, we would like to call this newly define render method instead of the default render method.
Create new jsp file renderAfterAction under /WEB-INF/jsp folder and just enter one line content in it like “<h1>This is Render After Action JSP </h1>“

Modify action method as per below code snippet.

@ActionMapping(params = "action=actionOne")
 public void actionOneMethod(ActionRequest request, ActionResponse response) {
  String userName=ParamUtil.get(request, "userName", "");
  log.info("userName is==>"+userName);
  response.setRenderParameter("action", "renderAfterAction");
 }

Explanation:-

  • The only change we have done is added last line code response.setRenderParameter(“action”, “renderAfterAction”);
  • This will tell the controller that after executing the action method, set render parameter action to “renderAfterAction“.
  • It means, the action method wants to execute a specific render method with a value of the action key set to  renderAfterAction
  • So after executing this action method it will execute testRenderMethod (whose value of action key is renderAfterAction)
Note:- setRenderParameter method is available only for objects of type ActionResponse.

Deploy the folder and it will show defaultRender JSP. Give the name “Nilang” and click on Submit button. You will see the render method renderAfterAction get execute as per the below screenshot.
Multiple render and action methods in Spring MVC portlet - render-after-action
You also can notice the log to understand the flow as per below screenshot.
log2
You can notice that after the action method gets executed, control goes to the testRenderMethod method. It’s done. you can try some more Actions and Render method combinations to get more dipper knowledge.

Summing Up

  • Spring MVC Portlet supports multiple render and action methods.
  • Multiple render and action methods are useful to define multiple render and action logic.
  • Liferay MVC Portlet supports one render and multiple action methods while spring MVC portlet allow to define multiple render and action methods.

I would recommend looking at the index page ‘A Complete Liferay Guide‘ to browse all topics about Liferay.
