In this article we will see how to create Liferay Portlet with MVC framework. Liferay MVC is portlet framework define by Liferay to create JSR-168 / JSR-286 compatible portlets. Liferay IDE (eclipse with liferay plugin or Liferay developer studio) can be used to create Liferay MVC portlet. However we can create Liferay Portlet from command prompt also. In this acticle we will see how to create Liferay MVC portlet by both these ways.
Create Liferay Portlet from command prompt
After giving this command, BUILD SUCCESSFUL message will be shown as above. Also if you observe under {plugin-SDK}/portlets folder, a new folder hello-word-portlet will be created as below
Create Liferay Portlet from Liferay IDE
You need to make eclipse ready to work with liferay. For this you can either configure Liferay with Eclipse or use Liferay developer studio.
Start eclipse and click on File->New->Project. Then select Liferay Project under Liferay category and click on Next button.
Now make sure that in the Plugin Type section, the default Portlet is selected because we are going to create portlet project.
In Configuration section, you need to specify Plugin SDK and Portal Runtime (Liferay-Tomcat server). Without this, wizard will not allow to process further.
Now click on Next button. Now you can see the following screen.
As we can create portlet on different technologies, this wizard allow us to create three different type of portlets.
Choose Liferay MVC (which is by default selected) and click on finish button. You will observe that project with name hello-word-portlet is created. Notice that, -portlet is appended to project name. The folder structure of this project will be looks like as below screenshot.
You can observe the following things
- The Java source folder is created under docroot /WEB-INF/src folder. All java classes are kept at this place.
- Configuration files are stored under docroot/WEB-INF folder. These configuration files are comprised of standard JSR-286 portlet configuration file portlet.xml and other three Liferay-specific configuration files as below
- liferay-display.xml:- This file describes the category of the portlet, which will appear under Add menu. (from the top bar after login as Liferay Admin).
- liferay-portlet.xml:- This file describes some additional Liferay-specific features on top of JSR-286. Ex. We can declare the portlet as instantiable from this file. Instantiable means we can place more than one portlet instance on the same page.
- liferay-plugin-package.properties:- We can configure dependency Jars and TLDs through this file.
<portlet-app version="2.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns="http://java.sun.com/xml/ns/portlet/portlet-app_2_0.xsd" xsi:schemalocation="http://java.sun.com/xml/ns/portlet/portlet-app_2_0.xsd http://java.sun.com/xml/ns/portlet/portlet-app_2_0.xsd"> <portlet> <portlet-name>hello-word</portlet-name> <display-name>Hello Word</display-name> <portlet-class>com.liferay.util.bridges.mvc.MVCPortlet</portlet-class> <init-param> <name>view-jsp</name> <value>/view.jsp</value> </init-param> <expiration-cache>0</expiration-cache> <supports> <mime-type>text/html</mime-type> </supports> <portlet-info> <title>Hello Word</title> <short-title>Hello Word</short-title> <keywords>Hello Word</keywords> </portlet-info> <security-role-ref> <role-name>administrator</role-name> </security-role-ref> <security-role-ref> <role-name>guest</role-name> </security-role-ref> <security-role-ref> <role-name>power-user</role-name> </security-role-ref> <security-role-ref> <role-name>user</role-name> </security-role-ref> </portlet> </portlet-app>
- portlet-name:- Unique name of portlet across. In the Liferay portal, it’s also referred to as portlet-id.
- display-name:- Short name of the portlet that will be used by the tool. It’s not required to be unique.
- portlet-class:- fully qualified portlet class name.
- init-param:- Just like servlet, we can pass init param for portlet.
- expiration-cache:- defines a time in second after which portlet output expires. -1 means never expire.
- supports:- support mime type.
- portlet-info:- define portlet information.
- security-role-ref:-will define which role can access this portlet.
<liferay-portlet-app> <portlet> <portlet-name>hello-word</portlet-name> <icon>/icon.png</icon> <instanceable>true</instanceable> <header-portlet-css>/css/main.css</header--portlet-css> <footer-portlet-javascript>/js/main.js</footer-portlet-javascript> <css-class-wrapper>hello-word-portlet</css-class-wrapper> </portlet> <role-mapper> <role-name>administrator</role-name> <role-link>Administrator</role-link> </role-mapper> <role-mapper> <role-name>guest</role-name> <role-link>Guest</role-link> </role-mapper> <role-mapper> <role-name>power-user</role-name> <role-link>Power User</role-link> </role-mapper> <role-mapper> <role-name>user</role-name> <role-link>User</role-link> </role-mapper> </liferay-portlet-app>
- portlet-name:- unique name of the portlet (this should be the same as what we have defined in portal.xml file).
- icon:- path to the image or icon.
- instanceable:- defines whether multiple instances of this portlet can be placed on the same page or not.
- header-portlet-css:- path of CSS files which will be included in the <head> section of final portlet output.
- footer-portlet-javascript:- path of .js files for this portlet which will be included at the and of page before </body> tag.
username:-test@liferay.com
password:-test
On the first-time login, it will ask for a password reminder. Pls give proper password and go further.
Now we will first build and deploy the Liferay portlet.
Open Ant window if it’s not already opened from Window–>Show View–>Ant menu option. Find build.xml in the project and drag it to Ant window as mentioned below screenshot.
A portlet is deployed on the server. Next, we will place the portlet on-page. Pls back to the browser where are already on the Welcome page after login. We will create a new page called ‘test’ and will place hello-word-portlet on it.
To create the page, click on Add from the top horizontal bar and click on Page. You will see text box just next to the Welcome page asking for the page name. Type test and click on the right tick mark just beside it.
Now click on the test page and then again click on Add from the top horizontal bar and click on More… You will observe that our portlet name will be just under the Sample category (which is defined in liferay-display.xml file.
Now click on Add link against the Hello Word name. You will notice that our Hello Word portlet has been placed on the page.
Here there are two Hello Word portlets you can see. One which is coming with Liferay (out of the box) and the second which we defined.
The one which comes with Liferay is not instantiable (with purple color icon) and the one which we have created is instantiable(with green color icon).
You can try putting multiple Hello Word portlet which we have created, but you won’t able to place multiple instances of the one which comes with Liferay.
The portlet which we have developed is just displayed one line This is the Hello Word portlet. This is because in the view.jsp file if you observe then you will find the same line.
Now you can change the content in view.jsp and re-deploy the portlet and refresh the test page and see your changes.
Summing up
- We created Liferay portlet with the Liferay MVC framework.
- com.liferay.util.bridges.mvc.MVCPortlet will work as the main portlet class.
- Path of JSP (view.jsp in our case) which is responsible for generating portlet content can be defined in portlet.xml file
- In real life, we need more customization.
- It’s possible to extend Liferay MVC and provide custom functionality, refer to a blog on how to write a custom Liferay MVC portlet.
Download Source
